Tiburon V6-2.7L (2004)
11. Tap the rotor side of the shaft slightly with a plastic hammer to remove the shaft.
12. Remove the oil seal from the oil pump body.
13. Remove the connector from the oil pump body, and take out the flow control valve and the flow control spring.
14. Remove the O-ring from the connector.
CAUTION: Do not disassemble the flow control valve.
INSPECTION
1. Check the free length of the flow control spring.
Free length of the flow control spring............................36.5 mm
2. Check that the flow control valve is not bent.
3. Check the shaft for wear and damage.
4. Check the V-belt for wear and deterioration.
