XG 350 V6-3.5L (2002)
5. Remove the engine mounting bracket.
CAUTION: Before removing the engine mounting bracket support the engine oil pan with a jack or equivalent so as not to go down the engine.
6. Disconnect the connectors from the timing belt upper cover and remove the upper cover.
7. Remove the drive belt and loosen the 2 alternator mounting nut (14 mm) and 2 bolts (12 mm) connecting the engine support bracket.
8. Loosen the 5 engine support bracket bolts.
CAUTION: To loosen the bolt shown in the forward of engine, first disconnect the alternator.
9. Remove the engine support bracket bolt by moving the engine up and down slightly and remove the bracket upward.
10. Remove the auto tensioner.
