Amigo 2WD L4-2.3L (4ZD1) (1989)

  • Maintenance
  • Tune-up and Engine Performance Checks
  • Fuel Pressure
  • System Information
  • Specifications

Page 1
background image

Fig. 10 Fuel System Pressure Specifications
