Ascender 4WD L6-4.2L (2003)
Suspension Strut / Shock Absorber: Service and Repair
Front Suspension
Shock Module Replacement
This article has been updated by TSB# SB06-06-S003 dated October,2006.
Shock Module Replacement
Removal Procedure
Tools Required
^
J 36607 Ball Joint Separator
1. Remove the shock module upper retaining nuts.
Notice: Use care when handling the coil springs in order to avoid chipping or scratching the coating. Damage to the coating will result in
premature failure of the coil springs.
2. Raise and support the vehicle.
3. Remove the tire and wheel.
4. Remove the shock module yoke to lower control arm retaining nut.
