Axiom XS 2WD V6-3.5L (2002)
Front Door Window Motor: Service and Repair
Power Window Motor
Driver Seat Side
Removal
1. Disconnect the battery ground cable.
2. Remove the window regulator assembly (2).
3. Remove the power window motor (1).
-
Remove three screws.
Installation
To install, follow the removal steps in the reverse order.
