Hombre S Space Cab 2WD V6-4.3L (2000)
Tailgate Hinge: Service and Repair
Removal Procedure
1. Remove the endgate. Refer to Endgate Replacement.
2. Remove the bolts that retain the pickup box endgate hinges to the endgate.
3. Remove the pickup box endgate hinges from the endgate.
4. Remove the bolts that retain the pickup box endgate hinges to the pickup box.
5. Remove the pickup box endgate hinges from the pickup box.
Installation Procedure
