Hombre XS Regular Cab 2WD L4-2.2L CPC (1998)
Dome Lamp Bulb: Service and Repair
Remove or Disconnect
1. Battery negative cable. Refer to Battery Disconnect Caution in Cautions and Notes.
2. Dome lamp lens by squeezing the lens to release the tabs.
3. Dome lamp bulb from the base.
4. Screws that retain the dome lamp base to the high mount stop lamp from inside the vehicle.
5. Dome lamp base from the vehicle.
Install or Connect
1. Dome lamp base to the vehicle.
2. Screws that retain the dome lamp base to the high mount stop lamp from inside the vehicle.
Tighten
-
Dome lamp base to the high mount stop lamp screws to 2.5 N.m (22 lb in).
3. Dome lamp bulb to the base.
4. Dome lamp lens by squeezing the lens to engage the tabs.
5. Battery negative cable Refer to Battery Disconnect Caution in Cautions and Notes.
