Timing Belt: Service and Repair

Make

Isuzu

Model

Impulse

Engine

L4-1994cc 2.0L

Year

1985

Section

Timing Belt › Service and Repair

MaintenanceService and Repair · page 1 of 2

Timing Belt: Service and Repair

Fig. 14 Timing belt cover, belt & sprocket assembly.

    Refer to Fig. 14 for removal and installation of timing belt.

1.

Disconnect battery ground cable.

Fig. 19 Aligning crankshaft timing pulley & front oil seal retainer

Fig. 20 Aligning camshaft timing pulley & front plate

2.

Align crankshaft timing pulley and camshaft timing pulley, Figs. 19 & 20.

3.

Remove tension spring.
