Drive Belt: Specifications
 Belt Tension

 Belt Tension

New Belt Tension

Used Belt Tension









A/C & Power Steering

0.4 inch

0.4 inch

Applying finger pressure of approximately 22 pounds force

Applying finger pressure of approximately 22 pounds force











Generator

between 0.16-0.2 inch

between 0.16-0.2 inch

Applying finger pressure of approximately 22 pounds force

Applying finger pressure of approximately 22 pounds force
