NPR L4-5.2L DSL Turbo (2005)
High Idle Switch: Service and Repair
Idle Up Volume Replacement
Removal Procedure
1. Turn off the ignition.
2. Remove the idle up volume knob (1).
3. Disconnect the idle up volume connector.
4. Remove the idle up volume holder (2).
5. Remove the idle up volume.
Installation Procedure
1. Install the idle up volume.
2. Install the idle up volume holder (2).
3. Install the idle up volume knob (1).
4. Connect the idle up volume connector.
