Rodeo 2WD V6-3.2L (2003)
Front Fender: Service and Repair
Front Fender Panel
Parts Location
Removal
1. Disconnect the battery ground cable.
2. Remove the radiator grille assembly.
3. Remove the front turn signal light assembly.
-
Remove the fixing screw and disconnect the connector.
