Rodeo LSE 4WD V6-3.2L (2000)
Control Module: Service and Repair
4WD Control Unit
4WD CONTROL UNIT ASSOCIATED PARTS
REMOVAL
1. Remove center console assembly.
2. Remove two screws and harness connector (1) from 4WD control unit.
INSTALLATION
1. Connect harness connector, then install 4WD control unit.
2. Install center console assembly.
