Trooper LS 2WD V6-3.5L (2001)
c. Align the alignment mark (white line) on the timing belt with alignment mark on the RH bank camshaft drive gear pulley (on the left side as
viewed from the front of the vehicle). Secure the belt with a double clip.
d. Align the alignment mark (white line) on the timing belt with the alignment mark on the LH bank camshaft drive gear pulley. When aligning
the timing marks, use a wrench to turn the camshaft drive gear pulley, then set the timing mark between timing belt and camshaft drive gear
pulley. Secure the belt with a double clip.
Note: It is recommended for easy installation that the belt be secured with a double clip after it is installed to each pulley.
e. Install crankshaft pulley temporarily and tighten center bolt by hand (do not use a wrench). Turn the crankshaft pulley clockwise to give some
belt slack between the crankshaft timing pulley and the RH bank camshaft drive gear pulley.
