Trooper LTD 2WD V6-3.5L (2001)
Caution: The pusher prevents air from entering the oil chamber. Its rod must always be facing upward.
14. Remove timing belt.
Caution:
1. Do not bend or twist the belt, otherwise its core could be damaged. The belt should not be bent at a radius less than 30 mm.
2. Do not allow oil or other chemical substances to come in contact with the belt They will shorten the life.
3. Do not attempt pry or stretch the belt with a screw driver or any other tool during installation.
4. Store timing belt in a cool and dark place. Never expose the belt direct sunlight or heat.
Installation
