Sovereign L6-4.0L (1991)
-
Fit and align tool JD 1D to the hub.
-
Fit and tighten the securing nuts.
-
Carefully tighten the centre bolt to withdraw the hub from the drive shaft.
-
Remove the tool securing nuts.
-
Remove tool JD 1D.
-
Remove the thread protector.
-
Carefully displace and remove the fulcrum shaft and displace and remove the hub assembly.
-
Fit and align the hub assembly to a vice.
-
Using a suitable drift, displace the fulcrum bearing tube.
-
Displace and remove the shim and bearing from the tube.
-
Displace and remove the remaining bearing and shim from the hub carrier.
-
Fit and align the extractor tool 1 8G 284 AAH (1) to the fulcrum bearing race.
-
Tighten the tool cross bolt, ensuring that the tool legs locate behind the bearing race.
-
Fit and tighten the slide hammer 1 8G 284 to the tool.
-
Using a slide hammer displace and remove the bearing race.
-
Slacken but DO NOT REMOVE the tool cross bolt.
-
Place the bearing race aside.
-
Repeat the above procedure for the remaining bearing race.
-
Fit and align extractor tool 1 8G 284 AAH to the fulcrum bearing race.
-
Using a slide hammer displace and remove the bearing race.
-
Slacken but DO NOT REMOVE the tool cross bolt.
-
Place the bearing race aside.
-
Remove the slide hammer from the tool, place slide hammer and tool aside and open the vice.
-
Remove the hub assembly and clean hub carrier fulcrum bearing faces.
-
Clean the cross shaft and tube.
-
Position the hub assembly to the press.
-
Fit and seat the bearing race replacer tool JD 5506
-
Fit a new bearing race to the replacer tool.
