Starting and ChargingDiagrams · page 4 of 5
Battery: Testing and Inspection
INSPECTION
Battery Diagnostic Flow Inspection
BATTERY DIAGNOSTIC FLOW
LOAD TEST
1. Perform the following steps to complete the load test procedure for maintenance free batteries.
2. Connect the load tester clamps to the terminals and proceed with the test as follow:
1. If the battery has been on charge, remove the surface charge by connect a 300 ampere load for 15 seconds.
2. Connect the voltmeter and apply the specified load.
3. Read the voltage after the load has been applied for 15 seconds.
4. Disconnect the load.
