Sephia RS Sedan L4-1.6L (1997)
Valve Body: Service and Repair
Control Valve Body Replacement
REMOVAL
NOTICE: Clean the transaxle exterior thoroughly with a steam cleaner or cleaning solvents before removal.
1. Support the engine with SST (or equivalent).
2. raise the vehicle and support it with safety stands.
3. Drain the ATF into a suitable container.
4. Remove the engine mounting member.
5. Remove the oil pan and gasket.
6. Disconnect all electrical connectors, remove eight bolts, and remove the control valve body.
INSTALLATION
