Sorento 2WD V6-3.3L (2008)
9. Install crankshaft sprocket(A)(O/P & RH camshaft drive).
10. Install oil pump chain(B) and oil pump sprocket(A).
Tightening torque
18.62 - 21.56Nm(1.9 - 2.2kgf.m, 13.74 - 15.91lb-ft)
11. Install RH timing chain guide(A).
Tightening torque
19.60 - 24.50Nm(2.0 - 2.5kgf.m, 14.17 - 18.08lb-ft)
12. Install RH timing chain.
To install the timing chain with no slack between each shaft (cam, crank), follow the below procedure.
Crankshaft sprocket(A) -> Intake camshaft sprocket(B) -> Exhaust camshaft sprocket(C).
The timing mark of each sprockets should be matched with timing mark (color link) of timing chain at installing timing chain.
