Page 6
background image

16. Remove the bolt(B) and timing belt idler (A).

17. Remove the crankshaft sprocket (A).
18. Remove the cylinder head cover.

1) Disconnect the spark plug cables and do not pull on the cable by force.

NOTE:  Pulling on or bending the cables may damage the conductor inside.
