Spectra L4-2.0L (2004)
CAUTION: Be careful not to damage the cylinder head and valve lifter with the wrench.
INSPECTION
SPROCKETS, TENSIONER, IDLER
1. Check the camshaft sprocket, crankshaft sprocket, tensioner pulley, and idler pulley for abnormal wear, cracks, or damage. Replace as necessary.
2. Inspect the tensioner pulley and the idler pulley for easy and smooth rotation and check for play or noise Replace as necessary.
3. Replace the pulley if there is a grease leak from its bearing.
TIMING BELT
1. Check the belt for oil or dust deposits.
Replace, if necessary.
Small deposits should be wiped away with a dry cloth or paper. Do not clean with solvent.
2. When the engine is overhauled or belt tension adjusted, check the carefully. If any damage is found, replace the belt.
NOTE:
-
Do not bend, twist or turn the timing belt inside out.
-
Do not allow timing belt to come into contact with oil, water and steam.
INSTALLATION
1. Install the camshaft sprocket and tighten the bolt to the specified torque.
1) Temporarily install the camshaft sprocket bolt(c).
2) Hold the portion(A) of the camshaft with a hexagonal wrench, and tighten the bolt(C) with a wrench(B).
Tightening torque: 98.1 - 117.7 Nm (10 - 12 kg-m, 72.3 - 86.8 ft. lbs.)
2. Install the cylinder head cover.
