Spectra5 L4-2.0L (2005)
Shifter A/T: Testing and Inspection
INSPECTION
1. Adjusting method for T/M control cable
1) Set room side lever and T/M side lever to "NO position.
2) Connect room side lever and shift cable.
3) Connect T/M side lever to cable in a following orders.
a. Push cable lightly to "F" direction shown to eliminate FREE PLAY of cable.
b. Tighten adjusting nut.
4) After adjusting according to (2) - (4). Check to be sure that this part operates surely at each range of T/M side corresponding to each position
of room lever.
2. Adjusting procedure for "P" shift lock cable
1) Install shift lock cable in position. In this case, shift lock cable must be fixed to brake pedal(brake pedal to be free condition) in position.
3. Checking item of shift lock
1) With shift lever at "P" position and brake pedal not depressed. Push button cannot be operated at the positions except "P".
2) With IG key at the position other than "LOCK" (may be at "ACC") and brake pedal stroke 25 - 35mm (0.984 - 1.378 inch) (with shin lever at
"Pa position). Push button can be operated and shift lever can be shifted smoothly to other from SPY.
3) With brake pedal not depressed. Shift lever can be shifted smoothly to "P" position from other positions.
4) Brake pedal must be operated smoothly without catching at all positions.
5) When shift lever shifted to Urn position again. IG key must be turned to "LOCK" position smoothly.
