Door Sensor/Switch (For Alarm): Service and Repair

Removal

1. Carefully lift rubber door switch cover and remove screw.
2. Remove door switch cover.
3. Remove the door switch then disconnect the wire harness connector.

Check

1. Check continuity between door switch terminals.

Installation

1. Install in the reverse order of removal.
