Wiring diagrams and electrical functionsEarths location components
EARTHS LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| C001 | Battery earth | |
| C010 | Left front earth | |
| C011 | Right front earth | |
| C012 | ABS front earth | |
| C015 | Driver''s dashboard earth | |
| C016 | Air conditioning unit earth | |
| C020 | Passenger dashboard earth | |
| C022 | Centre dashboard earth | |
| C030 | Left rear earth | |
| C031 | Right rear earth | |
| C032 | Rearscreen earth | |
| C040 | Earth on engine | |
| C050 | Air Bag system earth | |
| C055 | Side Bag system earth | |
| C056 | Amplifier earth | |
| C057 | Electric brake earth | |
| C058 | Radio diversity earth | |
| C059 | TV diversity earth | |
| C060 | Injection control unit earth | |
| C070 | TV tuner earth | |
| C094 | Passive entry aerial earth |
