Radio location components
- Make
- Lancia
- Model
- Thesis Factory Service Manual
- Year
- 2002–2009
- Section
- Radio accessories › Radio location components
Wiring diagrams and electrical functionsRadio location components
RADIO LOCATION COMPONENTS
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| C031 | Right rear earth | |
| C056 | Amplifier earth | |
| D020 | ||
| D030 | Left front door coupling | |
| D031 | ||
| D035 | Left rear door coupling | |
| D036 | ||
| D047 | ||
| D097 | Short circuit coupling | |
| D110 | CLOCK SPRING AND STEERING WHEEL CONTROLS COUPLING | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| M001 | Body computer | |
| M062 | 7040E | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M093 | STEERING WHEEL NODE CONTROL UNIT (NVO) | |
| P025 | Aerial feed/amplifier | |
| P031 | ||
| P035 | Speaker in left front door | 5570T |
| P036 | 5570T | |
| P040 | Speaker in left rear door | 5570T |
| P041 | 5570T | |
| P045 | ||
| P046 | Right front tweeter speaker | |
| P047 | Left rear tweeter speaker | |
| P048 | Right rear tweeter speaker | |
| P070 | Radio / CD amplifier | 5570T |
| P075 | CD Changer module |
Location Components
Components
| Component code | Name | Assembly reference |
|---|---|---|
| B002 | Junction unit under dashboard | |
| B045 | Luggage compartment junction unit (CVB) | 5505A |
| C015 | Driver''s dashboard earth | |
| C022 | Centre dashboard earth | |
| C056 | Amplifier earth | |
| D020 | ||
| D030 | Left front door coupling | |
| D031 | ||
| D035 | Left rear door coupling | |
| D036 | ||
| D047 | ||
| D097 | Short circuit coupling | |
| D110 | CLOCK SPRING AND STEERING WHEEL CONTROLS COUPLING | |
| E050 | Instrument panel | |
| H001 | Ignition switch | |
| M001 | Body computer | |
| M062 | 7040E | |
| M065 | Info-telematic control unit (NIT) | 5580P |
| M093 | STEERING WHEEL NODE CONTROL UNIT (NVO) | |
| P025 | Aerial feed/amplifier | |
| P032 | 5570T | |
| P035 | Speaker in left front door | 5570T |
| P036 | 5570T | |
| P040 | Speaker in left rear door | 5570T |
| P041 | 5570T | |
| P045 | ||
| P046 | Right front tweeter speaker | |
| P047 | Left rear tweeter speaker | |
| P048 | Right rear tweeter speaker | |
| P070 | Radio / CD amplifier | 5570T |
| P075 | CD Changer module | |
| P088 | ||
| P089 |
