Land Rover Defender Electrical Library (2002 on)05 · Connectors
05 · General

Description: Speaker - Rear - LH

Make
Land Rover
Model
Defender Electrical Library
Year
2002 on
Section
C0310 Speaker - Rear - LH › Description: Speaker - Rear - LH
ConnectorsDescription: Speaker - Rear - LH
Cav
1
Col
BO
Cct
41
Diagram

Description: Speaker - Rear - LH

Location: Behind LH rear trim panel

Description: speaker - rear - lh – Location: Behind LH rear trim panel

Colour: NATURAL Gender: Female
