300Tdi Defender
CHASSIS AND BODY
11
REPAIR
REMOTE CONTROL LEVER - FRONT DOOR
Service repair no - 76.37.31
Remove
1. Remove door trim casing
See Door trim
casing .
2. Peel back sufficient of plastic sheet to gain
access to remote lever.
3. Release spring clip and disconnect control rod
from latch mechanism.
4. Release control rod from plastic clip in mounting
panel.
5. Remove 2 screws securing remote control lever
to mounting panel and withdraw lever and
control rod.
Refit
6. Feed control rod into position and loosely secure
lever to mounting panel with 2 screws.
7. Connect control rod to latch mechanism and
secure with spring clip.
8. Tighten control lever retaining screws.
9. Secure control rod to plastic clip in mounting
panel.
10. Secure plastic sheet.
11. Fit door trim casing
See Door trim casing .
