300Tdi Defender
CHASSIS AND BODY
21
REPAIR
Refit
8. Secure seat belt straps to floor mounting.
Tighten bolt to
32 Nm (24 lbf/ft) and fit finisher
cap.
9. Feed belt straps between seat cushion and
squab.
10. Fit inertia reel to ’C’ post. Tighten bolt to
32 Nm
(24 lbf/ft).
11. Fit side trim panel
See Side trim panel .
12. Fit rear inward facing seats
See Rear seat
squab - 90 or See Rear bench seat .
SIDE TRIM PANEL - 90 STATION WAGON
Service repair no - 76.13.70
Remove
1. Remove rear seat squabs
See Rear seat
squab .
2. Remove rear end trim panel
See Rear end
trim panel .
3. Prise cap from front seat belt upper guide
retaining bolt.
4. Unscrew retaining bolt and remove seat belt
from ’B’ post.
5. Carefully prise trim stud from ’B’ post.
6. Remove 4 bolts securing side trim panel to body
side.
7. Release top edge of side trim panel by striking
upwards with the hand to disengage 3 spring
clips.
8. Lift trim panel from window surround and remove
from vehicle.
