Discovery II
ENGINE MANAGEMENT SYSTEM - V8
REPAIRS 18-2-87
Element - air filter
$% 19.10.10
Remove
1. Release 2 clips and disconnect MAF sensor
from air filter cover, remove and discard 'O'
ring.
2. Release 2 clips and remove cover from air
filter.
3. Remove air filter element.
Refit
1. Clean air filter body and cover.
2. Fit new air filter element.
3. Position air cleaner cover and secure clips.
CAUTION: Ensure clips are correctly
located on cover.
4. Fit a new MAF sensor 'O' ring, position MAF
sensor and secure clips.
CAUTION: Ensure 'O' ring is not displaced
during fitting.
