Discovery II
ENGINE MANAGEMENT SYSTEM - V8
18-2-88 REPAIRS
Cable - throttle
$% 19.20.06
Remove
1. Release 3 fasteners and remove drivers side
closing panel and move aside.
2. Release inner cable from throttle pedal.
3. Release outer cable from bulkhead.
4. Release outer cable from clip, loosen lock nuts
and remove outer cable from abutment
bracket.
5. Release inner cable from operating lever and
remove cable.
Refit
1. Position cable, secure to bulkhead and
connect inner cable to throttle pedal.
2. Position inner cable to operating lever and
connect outer cable to abutment bracket and
retaining clip.
3. Position closing panel and secure fasteners.
4. Adjust throttle cable.
