Discovery II
ENGINE MANAGEMENT SYSTEM - V8
REPAIRS 18-2-89
Sensor - Mass Air Flow (MAF)
$% 19.22.25
Remove
1. Disconnect multiplug from MAF sensor.
2. Loosen clip and release air intake hose from
MAF sensor.
Note: Pre 03 MY air intake hose illustrated.
3. Release 2 clips and remove MAF sensor from
air cleaner, remove and discard 'O' ring.
Refit
1. Fit new MAF sensor 'O' ring, position MAF
sensor to air cleaner and secure with clips.
CAUTION: Ensure 'O' ring is not displaced
during fitting.
2. Position air intake hose to MAF sensor and
secure with clip.
3. Connect multiplug to MAF sensor.
