Discovery II
SEATS
REPAIRS 76-5-29
17. Release clip securing front of cover to squab
frame.
18. Release hooks from squab frame.
19. Fold cover upwards over squab until first row of
hog rings are visible.
20. Remove first row of hog rings.
21. Fold cover upwards over squab until second
row of hog rings are visible.
22. Remove second row of hog rings.
23. Push out centres of trim clips securing stowage
pocket elastic to seat frame.
24. Remove trim clip outers.
25. Release hooks from seat frame and feed
though to front of foam.
26. Fold cover upwards until third row of hog rings
are visible.
27. Remove third row of hog rings.
28. Remove hog rings securing rear of squab
cover to seat frame.
29. Release bar from seat frame.
