Discovery II
SUNROOF
REPAIRS 76-6-17
Glass panel - sunroof
$% 76.84.03
The procedure for replacing the rear sunroof glass
panel is exactly the same as for the front
Remove
1. Partially open sunroof.
2. Remove 4 Torx screws securing glass to
sunroof frame.
3. Remove sunroof glass.
Refit
1. Position glass to frame.
2. Fit Torx screws securing glass to sunroof
frame. Do not fully tighten screws at this stage.
3. Adjust position of sunroof glass in relation to
roof panel until a 6.5 mm (0.25 in) gap is
produced between the front edge of the glass
and the sunroof frame.
4. Tighten sunroof glass retaining screws to 3 Nm
(2.2 lbf.ft).
