300Tdi Discovery
12
ENGINE
16
REPAIR
14. Release clip and disconnect brake servo hose
from manifold.
15. Disconnect fuel temperature sensor multiplug.
16. Remove 3 bolts securing engine harness to
manifold.
17. Disconnect fuel injection harness multiplug.
18. Disconnect inlet manifold air temperature sensor
multiplug.
19. Release clip and disconnect fuel hose from
pressure regulator.
CAUTION: Plug the connections
20. Release clips and disconnect 3 hoses from
manifold.
21. Remove bolt securing dipstick tube to coolant
rail.
