300Tdi Discovery
12
ENGINE
8
REPAIR
21. Release clip and disconnect inlet hose from
power steering pump.
22. Disconnect outlet pipe union at power steering
pump, discard ’O’ ring.
CAUTION: Plug the connections
23. Release throttle cable from abutment bracket.
24. Release throttle cable from cam. Also remove
coolant bypass hose from throttle housing.
25. Disconnect stepper motor and throttle
potentiometer multiplugs.
26. Release clip and disconnect hose, air cleaner to
throttle housing.
27. Release clip and disconnect brake servo hose
from manifold.
28. Disconnect fuel temperature sensor multiplug.
