300Tdi Discovery
CHASSIS AND BODY
35
REPAIR
AIR INTAKE PLENUM COWL
Service repair no - 76.11.08
Remove
1. Remove the windscreen wiper arms.
2. Remove the securing nuts and the steel and
rubber washers from the wiper spindles.
3. Open the vehicle bonnet [hood].
4. Remove the rubber seal from the cowl flange.
5. Release the screen washer tubes from the
washer jets on the cowl.
6. Remove the centre bolt securing the cowl centre
section.
7. Remove the retainers securing the centre
section to the outer section.
8. Detach the centre section from the bulkhead.
9. Remove the nuts and bolts and detach the outer
sections of the cowl.
Refit
10. Reverse removal procedure.
