300Tdi Discovery
CHASSIS AND BODY
63
REPAIR
SWITCH PACK - DASH PANEL CENTRAL LOUVRE
PANEL
Service repair no - 76.46.38
Remove
1. Release switch pack from louvre panel.
2. Disconnect 3 multiplugs from switch pack.
3. Remove switch pack.
Refit
4. Position switch pack.
5. Connect multiplugs to switch pack.
6. Secure switch pack to louvre panel.
GRAB HANDLE
Service repair no - 76.58.30
Remove
1. Release 2 grab handle retaining screw covers.
2. Remove 4 screws securing grab handle to body.
3. Remove grab handle.
4. Collect 2 washers.
Refit
5. Position grab handle and washers.
6. Fit and tighten screws securing grab handle to
body.
7. Secure grab handle retaining screw covers.
