Freelander Service Procedures
BRAKES
REPAIRS
70-23
Carrier assembly - calliper - front
$% 70.55.28
Remove
1. Raise front of vehicle.
WARNING: Do not work on or under a
vehicle supported only by a jack. Always
support the vehicle on safety stands.
2. Remove road wheel.
3. Remove 2 guide pins from calliper housing.
4. Release calliper housing from calliper carrier
and tie aside.
5. Remove 2 brake pads and retainers from
calliper carrier.
6. Remove 2 bolts securing calliper carrier and
remove carrier.
7. Remove guide pins and seals from carrier.
