Headlamp - RH
- Make
- Land Rover
- Model
- Freelander Electrical Library
- Year
- 1998–2000
- Section
- C011 › Headlamp - RH
ConnectorsHeadlamp - RH
Headlamp - RH
Female
BLACK
Behind RH headlamp
| Cav | Col | CCT |
|---|---|---|
| 1 | UG | ALL |
| 2 | GW | ALL |
| 3 | B | ALL |
| 4 | UB | ALL |
| 5 | RO | ALL |
| 6 | B | ALL |
