L322 Range Rover Service Procedures
ENGINE - V8
12-2-38 REPAIRS
52. Disconnect multiplug from A/C compressor.
53. Remove Allen bolt securing A/C pipe to A/C
compressor and disconnect A/C pipe. Discard
'O' ring.
CAUTION: Immediately cap all A/C pipes to
prevent ingress of dirt and moisture into the
system.
54. Remove Allen bolt securing A/C pipe to
condenser and disconnect A/C pipe. Discard
'O' ring.
CAUTION: Immediately cap all A/C pipes to
prevent ingress of dirt and moisture into the
system.
55. Disconnect 2 hoses from the SAI control valve.
CAUTION: Always fit plugs to open
connections to prevent contamination.
