GENERAL INFORMATION
03-24
For seat buckle type pre-tensioners, hold by the
piston tube, with the open end of the piston tube
pointing towards the ground and the buckle
facing away from your body. Do not cover the
end of the piston tube. DO NOT hold buckle type
pre-tensioners by the bracket assembly or cable.
Never point the piston tube towards your body or
other people.
SRS harness and connectors
Always observe the following precautions with
regards to SRS system electrical wiring:
CAUTION: Observe the following precautions:
l
Never attempt to modify, splice or repair
SRS wiring.
l
Never install electrical equipment such as a
mobile telephone, two-way radio or in-car
entertainment system in such a way that it
could generate electrical interference in the
airbag harness. Seek specialist advice when
installing such equipment.
NOTE: SRS wiring can be identified by a special
yellow outer sleeve protecting the wires (black with
yellow stripe protective coverings are sometimes
used).
WARNING: Always ensure SRS wiring is routed
correctly. Be careful to avoid trapping or
pinching the SRS wiring. Do not leave the
connectors hanging loose or allow SRS
components to hang from their harnesses. Look
for possible chafing points.
Side impact crash sensor inspection
After any degree of side body damage, inspect both
side impact crash sensors. Replace a crash sensor if
there is any sign of damage or deformation to the
sensor fixings.
M01 0270
