L322 Range Rover Service Procedures
INTERIOR FITTINGS
REPAIRS 76-3-19
13. Release clip securing harness to drivers side
footwell duct.
14. Identify position of harness for reassembly.
15. Note position for refit and remove foam strip
from ends of carrier.
16. Remove 10 Torx screws securing fascia carrier
and remove carrier.
NOTE: Do not carry out further dismantling if
component is removed for access only.
17. Remove 3 Torx screws securing drivers side
footwell duct and remove duct.
18. Remove 3 Torx screws securing LH demister
duct and remove duct.
19. Remove 3 Torx screws securing RH demister
duct and remove duct.
20. Remove 3 Torx screws securing drivers side
face level vent duct and remove duct.
M76 4449
M76 4453
