L322 Range Rover Service Procedures
INTERIOR FITTINGS
REPAIRS 76-3-17
Finisher - lower - passengers side
$% 76.46.14
Remove
1. Remove fascia end closing panel.
2. Remove RH lower 'A' post finisher.
Trim finisher - 'A' post - lower.
3. Remove passenger side footwell closing panel.
Closing panel - passenger side.
4. Remove cover from lower finisher for access to
Torx screw.
5. Remove 3 Torx screws securing upper finisher
to fascia.
6. Remove finisher.
7. Remove clips from finisher.
Refit
1. Fit clips to finisher.
2. Fit finisher to fascia and secure with screws.
3. Fit blanking plug to finisher.
4. Fit passenger side footwell closing panel.
Closing panel - passenger side.
5. Fit lower 'A' post finisher.
Trim finisher - 'A' post - lower.
6. Fit fascia end closing panel.
Finisher - lower - drivers side
$% 76.46.15
Remove
1. Remove fascia end closing panel.
2. Remove closing panel.
Closing panel - passenger side.
3. Remove LH lower 'A' post finisher.
4. Remove cover from lower finisher for access to
Torx screw.
5. Remove 3 Torx screws securing upper finisher
to fascia.
6. Disconnect on board diagnostics port multiplug,
if fitted
7. Remove finisher.
8. Remove clips from finisher.
Refit
1. Fit clips to finisher.
2. Connect on board diagnostics port multiplug.
3. Fit finisher to fascia and secure with screws.
4. Fit blanking plug to finisher.
5. Fit LH lower 'A' post finisher.
6. Fit closing panel.
Closing panel - passenger side.
7. Fit fascia end closing panel.
