Cover - squab - front seat - models with adjustable upper squab

SEATS

REPAIRS 76-5-29

Latch - rear squab

$% 78.80.05

Remove

1. Remove squab cover and pad from frame.

 +

 SEATS, REPAIRS, Cover - squab -

rear seat - RH.

2. Remove and discard retaining clip securing

operating rod to latch assembly.

3. Release operating rod from assembly.
4. Remove 2 Allen bolts securing latch assembly

to frame, remove assembly.

Refit

1. Position latch assembly to frame and secure

with Allen bolts, tighten to 25 Nm (18 lbf.ft).

2. Connect operating rod and secure with

retaining clip.

3. Fit squab cover and pad to frame.

 +

 SEATS, REPAIRS, Cover - squab -

rear seat - RH.

Cover - squab - front seat - models with
adjustable upper squab

$% 78.90.07

Remove

1. Remove seat assembly.

 +

 SEATS, REPAIRS, Front seat.

2. Release 3 backboard tension straps from under

seat.

M78 0628
