LR3/Disco 3
Installation
CAUTION: If power steering fluid comes into contact with the paintwork, the affected area
must be immediately washed down with cold water.
Disconnect the power steering pump supply hose.
Clamp the power steering pump supply hose to minimise fluid loss.
Install blanking caps to the exposed ports.
16 .
Remove the power steering pump.
Remove the three retaining bolts.
1 .
Install the power steering pump.
Loosely install the power steering pump rear retaining bolt.
2 .
Install the power steering pump front retaining bolts.
Install the three retaining bolts.
Tighten to 22 Nm (16 lb.ft).
3 .
Connect the power steering supply hose.
Remove the blanking caps from the ports.
Remove the hose clamp.
4 .
Tighten the power steering pump rear retaining bolt to 22 Nm (16 lb.ft).
5 .
