LR3/Disco 3
Installation
1 .
Install the safety belt buckle.
Attach the tension spring.
Tighten the Torx bolt to 25 Nm (18 lb.ft).
Fold seat assembly rearwards.
2 .
Install the rear seat cushion side finisher.
Attach the tension strap.
Tighten the screws.
3 .
Install the inner backrest hinge cover.
Attach the clips.
Tighten the screw.
Attach the backrest cover side clip.
