LAND ROVER V8

35

DESCRIPTION AND OPERATION

Connector 3 (C0636):

This connector contains 52 pins and is used for most sensor and actuator inputs and outputs. Sensor and actuator
control is vital to ensure that the ECM maintains adaptive strategy.

ECM pin details for Connector C0636:

Pin No.

Description

Input/Output

Voltage

1

Fuel injector cylinder number 2

Output drive

Switch to

ground

2

Fuel injector cylinder number 5

Output drive

Switch to

ground

3

Purge valve drive

Output signal

PWM 12 - 0V

4

SAI vacuum solenoid valve (NAS

vehicles from 2000MY only)

Output drive

Switch to

ground

5

Not used

-

-

6

Fuel tank pressure sensor (NAS

vehicles with Advanced EVAPS only)

Ground

0V

7

MAF sensor 5V supply

Output, reference

5V

8

Not used

-

-

9

MAF sensor earth

Ground

0V

10

Throttle pot sensor 5V supply

Output reference

5V

11

Not used

-

-

12

Not used

-

-

13

Not used

-

-

14

Fuel injector cylinder number 7

Output drive

Switch to

ground

15

Fuel injector cylinder number 6

Output drive

Switch to

ground

16

SAI pump relay (NAS vehicles from

2000MY only)

Output drive

Switch to

ground

17

Camshaft (CMP) sensor screen

Ground

0V

18

Not used

-

-

19

Not used

-

-

20

Camshaft (CMP) sensor signal

Input signal

Digital switch 0

- 12V

21

Coolant temperature (ECT) sensor

Ground

0V

22

Coolant temperature (ECT) sensor

signal

Input signal

Analogue 0 -

5V

23

MAF sensor signal

Input signal

Analogue 0 -

5V

24

Throttle potentiometer signal

Input signal

Analogue 0 -

5V
