19

FUEL SYSTEM

NEW RANGE ROVER

36

DESCRIPTION AND OPERATION

ECM pin details for Connector C0636 continued:

Pin No.

Description

Input/Output

Voltage

25

Throttle potentiometer

Ground

0V

26

Not used

-

-

27

Fuel injector cylinder number 3

Output drive

Switch to

ground

28

Fuel injector cylinder number 8

Output drive

Switch to

ground

29

Not used

-

-

30

Canister vent solenoid (CVS) shut-off

valve (NAS vehicles with Advanced

EVAPs only)

Output drive

Switch to

ground

31

Air conditioner condenser fan drive

Output drive

Switch to

ground

32

Crankshaft (CKP) sensor signal

Input signal

Analogue 0 -

300V pk.

33

Not used

-

-

34

Intake air temperature (IAT) sensor

Input signal

Analogue 0 -

5V

35

Knock sensor RH bank

Ground

0V

36

Knock sensor RH bank

Input signal

Analogue 0V

37

Not used

-

-

38

Not used

-

-

39

Not used

-

-

40

Fuel injector cylinder number 4

Output drive

Switch to

ground

41

Fuel injector cylinder number 1

Output drive

Switch to

ground

42

Idle speed actuator open

Output signal

PWM 12 - 0V

43

Idle speed actuator close

Output signal

PWM 12 - 0V

44

Instrument Pack - Coolant sensor output

Output signal

PWM 0 - 12V

45

Crankshaft position (CKP) sensor

screen ground

Ground

0V

46

Crankshaft position (CKP) sensor

reference ground

Ground

0V

47

Not used

-

-

48

Knock sensor LH bank

Ground

0V
