LAND ROVER V8

37

DESCRIPTION AND OPERATION

ECM pin details for Connector C0636 continued:

Pin No.

Description

Input/Output

Voltage

49

Knock sensor LH bank

Input signal

Analogue 0V

50

Not used

-

-

51

Not used

-

-

52

Not used

-

-

Connector 4 (C0637):

This connector contains 40 pins and facilitates the use of Testbook via the Diagnostic connector. Also contained in
this connector is the Malfunction Indicator Lamp (MIL), this instrument panel lamp informs the driver of concerns
within the engine management system.

ECM pin details for Connector C0637:

Pin No.

Description

Input/Output

Voltage

1

Not used

-

-

2

Not used

-

-

3

Not used

-

-

4

Not used

-

-

5

Not used

-

-

6

Not used

-

-

7

Not used

-

-

8

Low fuel level

Input signal

Active high

9

Fuel tank pressure sensor (NAS

vehicles with Advanced EVAPs only)

Output reference

5V

10

ECM E-box cooling fan

Output drive

Switch to

ground

11

Not used

-

-

12

BeCM Low fuel level signal

Ground

12V - 0V (when

fuel level low)

13

Not used

-

-

14

Fuel tank pressure sensor (NAS

vehicles with Advanced EVAPs only)

Input signal

Analogue 0 -

5V

15

Not used

-

-

16

Air conditioning compressor

Input signal

Active low

17

Engine speed output

Output signal

PWM 0 - 5V

18

Not used

-

-
