Range Rover P38
AIR CONDITIONING
15
REPAIR
THERMOSTATIC EXPANSION VALVE (TXV) - V8
FROM 99MY
Service repair no - 82.25.01
Remove
1. Depressurise A/C system.
See Adjustment.
2. Remove IAC valve.
See FUEL SYSTEM,
Repair.
3. Release throttle and cruise control cables from
clips on manifold chamber and position cables
aside.
4. Remove bolt securing engine harness mounting
bracket to manifold chamber.
5. Remove nut securing engine harness to bracket
on bulkhead and release harness.
6. Remove clamp securing A/C pipes to bulkhead.
7. Remove bolt securing A/C pipe clamp to TXV
and position clamp aside.
8. Release A/C pipes from TXV, discard ’O’ rings
and position pipes aside.
CAUTION: Immediately cap all air
conditioning pipes to prevent ingress of
dirt and moisture into the system.
