Range Rover P38
AIR CONDITIONING
1
REPAIR
INTERIOR TEMPERATURE SENSOR
Service repair no - 82.20.93
Remove
1. Remove instrument pack binnacle.
See
INSTRUMENTS, Repair.
2. Move front seats fully rearward.
3. Remove screw securing each side panel to
centre console.
4. Release sprag clip by firmly pulling panel
rearwards. Remove side panels.
5. Remove radio applique.
6. Remove 5 screws securing switch pack.
7. Release switch pack from fascia. Sensor is
located behind grille of switch panel.
8. Disconnect multiplug from interior temperature
sensor.
9. Remove 2 screws securing interior temperature
sensor. Remove sensor.
Refit
10. Reverse removal procedure.
